Dimension
|
Type |
A(mm) |
B(mm) |
H(mm) |
C(mm) |
Efficient Area（mm2） |
Weight（mg） |
|
ER707Z/K/6X2/00 |
12.5 |
7.2 |
2.5 |
0.55 |
56 |
290 |
|
ER707Z/K/6X3/00 |
15.5 |
9.0 |
2.4 |
0.55 |
100 |
390 |
|
ER707Z/K/8X2/00 |
12.5 |
7.2 |
3.4 |
0.55 |
56 |
500 |
|
ER707Z/K/10X2/00 |
17.5 |
11.5 |
2.4 |
0.55 |
157 |
830 |
Technical Characteristics
Recommended Active Condition (When the pressure is below 1Pa)
|
TEMPUTURE |
400℃ |
500℃ |
600℃ |
700℃ |
|
TIME |
15MIN |
10MIN |
8MIN |
4MIN |
